Modular Motors

Series: KU

Ex protection level: Ex II 3G Ex nA IIC T3, Ex II 2G Ex e IIC T3 Gb and Ex II 2G Ex px e ib IIC T3 Gb

Frame size: 400 - 1200

Voltages: 3 - 15 kV line and inverter operation

Power output: 160 - 17.000 kW

Frame construction: Fabricated steel

Mounting arrangments: B3, V1

Degree of protection: IP55, IP65

Number of poles : 2 - 24

Temperature class: 155 (F) according to 130 (B)

Certificates: ATEX, IEC-EX

Cooling method: IC81w

Series: KB / KF / KS

Frame size: 400 - 1200

Voltages: 3 - 15 kV line and inverter operation

Power output: 160 - 15.000 kW

Frame construction: Fabricated steel

Mounting arrangments: B3, V1, B35

Degree of protection: IP23

Number of poles : 2 - 24

Temperature class: 155 (F) according to 130 (B)

Certificates: CE

Cooling method: IC01, WPI, WPII
Bearings: Roling elements or sleeve bearings

Series: PZ

Frame size: 355 - 800

Voltages: 3 - 13,8 kV

Power output: 200 - 9.000 kW

Frame construction: Fabricated steel

Mounting arrangments: B3, V1

Degree of protection: IP55, IP65

Number of poles : 2 - 10

Temperature class: 155 (F) according to 130 (B)

Certificates: CE

Cooling method: IC611

Series: KV

Ex protection level: Ex II 3G Ex nA IIC T3, Ex II 2G Ex e IIC T3 Gb and Ex II 2G Ex px e ib IIC T3 Gb

Frame size: 500 - 1500

Voltages: 3 - 15 kV line and inverter operation

Power output: 160 - 17.000 kW

Frame construction: Fabricated steel

Mounting arrangments: B3, V1

Degree of protection: IP55, IP65

Number of poles : 2 - 24

Temperature class: 155 (F) according to 130 (B)

Certificates: ATEX, IEC-EX

Cooling method: IC611

Series: KU

Frame size: 400 - 1.200

Voltages: 2,3 - 15kV line and inverter operation

Power output: 160 - 17.000kW

Frame construction: Fabricated steel

Mounting arrangments: B3, V1

Degree of protection: IP55, IP65

Number of poles : 2 - 24

Temperature class: 155 (F) according to 130 (B)

Certificates: CE

Cooling method: IC611

Bearings: Roling elements and sleeve bearings

Series: KV

Frame size: 400 - 1.200

Voltages: 2,3 - 15kV line and inverter operation

Power output: 160 - 17.000kW

Frame construction: Fabricated steel

Mounting arrangments: B3, V1

Degree of protection: IP55, IP65

Number of poles : 2 - 24

Temperature class: 155 (F) according to 130 (B)

Certificates: CE

Cooling method: IC611

Bearings: Roling elements and sleeve bearings
