WXF HIGH TEMPRATURE MOTORS

Get the power, reliability, and durability your mining applications demand with Mining Motors. Built for tough conditions, these motors ensure consistent performance and a long service life.

• Designed for heavy-duty mining applications
• Built to withstand harsh operating conditions
• Ensures consistent performance
• Long service life
• Comprehensive range with quick availability

Discover superior industrial efficiency with the nan Mining motor motors�engineered for precision, durability, and energy-saving performance. Perfect for high-demand applications, this motor combines powerful output with reliable operation to keep your production running at peak capacity.
Mining motor

Series: KR

Ex protection level: II 3G Ex nA II T1-T4 Gc

Frame size: 500 - 1700

Voltages: 3 - 15 kV line and inverter operation

Power output: 160 - 17.000 kW

Frame construction: Fabricated steel

Mounting arrangments: B3, V1

Degree of protection: IP55, IP65

Number of poles : 2 - 24

Temperature class: 155 (F) according to 130 (B)

Certificates: ATEX, IEC-EX

Cooling method: IC511

Series: KR

Ex protection level: Ex d IIB or C T4 Gb and Ex de IIB or C T4 Gb

Frame size: 500 - 1500

Voltages: 3 - 15 kV line and inverter operation

Power output: 160 - 13.200 kW

Frame construction: Fabricated steel

Mounting arrangments: B3, V1

Degree of protection: IP55, IP65

Number of poles : 2 - 24

Temperature class: 155 (F) according to 130 (B)

Certificates: ATEX, IEC-EX

Cooling method: IC511

Series: KU

Ex protection level: Ex II 3G Ex nA IIC T3, Ex II 2G Ex e IIC T3 Gb and Ex II 2G Ex px e ib IIC T3 Gb

Frame size: 400 - 1200

Voltages: 3 - 15 kV line and inverter operation

Power output: 160 - 17.000 kW

Frame construction: Fabricated steel

Mounting arrangments: B3, V1

Degree of protection: IP55, IP65

Number of poles : 2 - 24

Temperature class: 155 (F) according to 130 (B)

Certificates: ATEX, IEC-EX

Cooling method: IC81w

Series: KB / KF / KS

Frame size: 400 - 1200

Voltages: 3 - 15 kV line and inverter operation

Power output: 160 - 15.000 kW

Frame construction: Fabricated steel

Mounting arrangments: B3, V1, B35

Degree of protection: IP23

Number of poles : 2 - 24

Temperature class: 155 (F) according to 130 (B)

Certificates: CE

Cooling method: IC01, WPI, WPII
Bearings: Roling elements or sleeve bearings

Series: PZ

Frame size: 355 - 800

Voltages: 3 - 13,8 kV

Power output: 200 - 9.000 kW

Frame construction: Fabricated steel

Mounting arrangments: B3, V1

Degree of protection: IP55, IP65

Number of poles : 2 - 10

Temperature class: 155 (F) according to 130 (B)

Certificates: CE

Cooling method: IC611

The PT Series motors offer high torque and robust performance for industrial applications, ensuring consistent power and reliability. Built for durability, these motors are ideal for heavy-duty equipment like crushers and conveyors.

• High torque performance
• Robust industrial design
• Durable construction
• Minimal maintenance required
• Flexible delivery options

Series: KV

Ex protection level: Ex II 3G Ex nA IIC T3, Ex II 2G Ex e IIC T3 Gb and Ex II 2G Ex px e ib IIC T3 Gb

Frame size: 500 - 1500

Voltages: 3 - 15 kV line and inverter operation

Power output: 160 - 17.000 kW

Frame construction: Fabricated steel

Mounting arrangments: B3, V1

Degree of protection: IP55, IP65

Number of poles : 2 - 24

Temperature class: 155 (F) according to 130 (B)

Certificates: ATEX, IEC-EX

Cooling method: IC611

Series: KU

Frame size: 400 - 1.200

Voltages: 2,3 - 15kV line and inverter operation

Power output: 160 - 17.000kW

Frame construction: Fabricated steel

Mounting arrangments: B3, V1

Degree of protection: IP55, IP65

Number of poles : 2 - 24

Temperature class: 155 (F) according to 130 (B)

Certificates: CE

Cooling method: IC611

Bearings: Roling elements and sleeve bearings

Series: KV

Frame size: 400 - 1.200

Voltages: 2,3 - 15kV line and inverter operation

Power output: 160 - 17.000kW

Frame construction: Fabricated steel

Mounting arrangments: B3, V1

Degree of protection: IP55, IP65

Number of poles : 2 - 24

Temperature class: 155 (F) according to 130 (B)

Certificates: CE

Cooling method: IC611

Bearings: Roling elements and sleeve bearings

Series: KA2

Frame size: 315 - 560

Voltages: 2,3 - 15kV line and inverter operation

Power output: 160 - 19.000kW

Frame construction: Cast iron

Mounting arrangments: B3, V1, B35, B5

Degree of protection: IP55, IP56, IP65

Number of poles : 2 - 16

Temperature class: 155 (F) according to 130 (B)

Certificates: ATEX, IEC-EX

Cooling method: IC411

Ex protection level: II 3G Ex nA II T1-T4 Gc

Series: KA3

Frame size: 315 - 500

Voltages: 2,3 - 15kV line and inverter operation

Power output: 180 - 16.000kW

Frame construction: Cast iron

Mounting arrangments: B3, V1, B35

Degree of protection: IP55, IP56, IP65, IP66

Number of poles : 2 - 16

Temperature class: 155 (F) according to 130 (B)

Certificates: CE

Cooling method: IC411

Bearings: Roling elements and sleeve bearings

Series: KD2

Frame size: 355 - 500

Voltages: 2,3 - 15kV line and inverter operation

Power output: 180 - 16.000kW

Frame construction: Cast iron

Mounting arrangments: B3, V1, B35

Degree of protection: IP55, IP56, IP65

Number of poles : 2 - 16

Temperature class: 155 (F) according to 130 (B)

Certificates: CE

Cooling method: IC411

Ex protection level: Ex d IIB or C T4 Gb and Ex de IIB or C T4 Gb

Series: KE2

Frame size: 315 - 560

Voltages: 2,3 - 15kV line

Power output: 160 - 1330kW

Frame construction: Cast iron

Mounting arrangments: B3, V1, B35, B5

Degree of protection: IP55, IP56, IP65

Number of poles : 2 - 16

Temperature class: 155 (F) according to 130 (B)

Certificates: ATEX, IEC-EX

Cooling method: IC411

Ex protection level: Ex II 2 G Ex e IIC T3 Gb

Series: KZX

Frame size: 315 - 500

Voltages: 2,3 - 15kV line and inverter operation

Power output: 375 - 1320kW

Frame construction: Fabricated steel

Mounting arrangments: B3, V1, B35

Degree of protection: IP55, IP56, IP65, IP66

Number of poles : 2 - 16

Temperature class: 155 (F) according to 130 (B)

Certificates: CE

Cooling method: IC411

Bearings: Roling elements and sleeve bearings

Series: KA5 H-OPTIM

Frame size: 315 - 560

Voltages: 2,3 - 15kV line and inverter operation

Power output: 375 - 1320kW

Frame construction: Cast Iron

Mounting arrangments: B3, V1, B35

Degree of protection: IP55, IP56, IP65, IP66

Number of poles : 2 - 16

Temperature class: 155 (F) according to 130 (B)

Certificates: CE, Zone 2/22 (IEC), Cl. I Div.2 (NEC)

Cooling method: IC411, IC410, IC416

Bearings: Roling elements and sleeve bearings
