Medium / High Voltage Motors

Filters

KE2 series Ex e increased safety

Request Quote

KE2 series Ex e increased safety

Series KE2 Ex protection level

Ex II 2 G Ex e IIC T3 Gb

Frame size 315 - 560 Voltages 3 - 11 kV line Power output 160 - 1.330 kW Frame construction Cast iron Mounting arrangments B3, B5, B35,V1 Degree of protection IP55,IP56, IP65 Number of poles 2 - 16 Temperature class 155 (F) according to 130 (B) Certificates ATEX, IEC-EX Cooling method IC411

Request Quote

Finer series

Series KA5 H-OPTIM Voltages

2,3 - 11kV line and inverter operation

Frame size 315 - 560 Frame construction Cast Iron Power output 180 - 2.250kW Degree of protection IP55 Mounting arrangements B3, V1, B35 Temperature class 155 (F) according to 130 (B) Number of poles 2 - 12 Cooling method IC411, IC410, IC416 Bearings Roling elements and sleeve bearings Certificates CE, Zone 2/22 (IEC), Cl. I Div.2 (NEC)

Request Quote

KV series

Series KV Voltages

2,3 - 15kV line and inverter operation

Frame size 400 - 1.200 Frame construction Fabricated steel Power output 160 - 17.000kW Degree of protection IP55, IP65 Mounting arrangements B3, V1 Temperature class 155 (F) according to 130 (B) Number of poles 2 - 24 Cooling method IC611 Bearings Roling elements and sleeve bearings Certificates CE

Request Quote

PZ wound rotor series

Series PZ Voltages

3 - 13,8 kV

Frame size 355 - 800 Frame construction Fabricated steel Power output 200 - 9.000 kW Degree of protection IP55, IP65 Mounting arrangments B3, V1 Temperature class 155 (F) according to 130 (B) Efficiency class
Cooling method IC611 Number of poles 2 - 10 Certificates CE

Request Quote

KU series hazardous area

Series KU Ex protection level

Ex II 3G Ex nA IIC T3

Ex II 2G Ex e IIC T3 Gb

Ex II 2G Ex px e ib IIC T3 Gb

Frame size 400 - 1.200 Voltages 3 - 15 kV line and inverter operation Power output 160 - 17.000 kW Frame construction Fabricated steel Mounting arrangments B3, V1 Degree of protection IP55,IP65 Number of poles 2 - 24 Temperature class 155 (F) according to 130 (B) Certificates ATEX, IEC-EX Cooling method IC81W

Request Quote

KR series Ex n non sparking

Series KR Ex protection level

II 3G Ex nA II T1-T4 Gc

Frame size 500 - 1700 Voltages 3 - 15 kV line and inverter operation Power output 160 - 17.000 kW Frame construction Fabricated steel Mounting arrangments B3, V1 Degree of protection IP55,IP65 Number of poles 2 - 24 Temperature class 155 (F) according to 130 (B) Certificates ATEX, IEC-EX Cooling method IC511

Request Quote

PT series

Discover superior industrial efficiency with the Wolong PT series motors�engineered for precision, durability, and energy-saving performance. Perfect for high-demand applications, this motor combines powerful output with reliable operation to keep your production running at peak capacity.
PT series

Request Quote

Mining motor

Brand Wolong Morley Ex protection level
Frame size
Voltages
Power output
Frame construction
Mounting arrangments
Degree of protection
Number of poles
Temperature class
Certificates
Cooling method

Request Quote
