Engineered Products

Overview

Specially modified motors designed for above deck and offshore (wet environments) and below deck (dry environments) capable of meeting multiple Marine agency certifications and requirements.

Sizes

.2-1,500Hp, .1-1,120kW: 115-4000 VAC, TEFC, TENV, DPP, or TEWC: NEMA & IEC frame sizes

Features

Marine duty epoxy paint, corrosion resistant hardware, commercial VPI windings, steel, casting iron, or ductile iron construction, spraytight, watertight, explosion proof enclosures. Certifications include: ABS, Lloyds Registry, DNV, USCG-256, IEEE-45-2002, and NEMA MG1

Suggested applications

Pumps, fans, deck equipment, thrusters, auxiliary propulsion, winches, capstans

Overview

Totally-enclosed, XP motors designed for underground coal mining, coal preparation, or transportation of mined coal.

Sizes

AC: 2-225 kW, 5-300 Hp, 230-1000 VAC, TEFC, TENV, or TEWC; NEMA & IEC frame sizes

DC: 20-50 Hp, 110-460 VDC, TENV or TEWC, NEMA frame sizes

Features

Designed and certified for hazardous mining atmospheres. Meets or exceeds global high efficiency energy standards. Special shaft configurations, double shaft extensions, and flange mounting configurations available. Global certifications include MSHA, ATEX, ANZEx, and IECEx.

Suggested applications

Pumps, fans, conveyors, and traction motors for continuous and longwall miners, feeder breakers, roof bolters, and haulers/scoops.

Overview

Motors designed for optimized performance and longer life on critical above deck and below deck applications.

Sizes

.2-500Hp, .1-375kW: 115-690 VAC, TEFC, TENV, DPP, or TEWC: Spraytight, Watertight, Explosion Proof, Submersible Enclosures: NEMA & IEC frame sizes

Features

Motors meet all pertinent military specifications for fractional and integral AC motors including critical specifications pertaining to energy efficiency, sealed insulation, reduced weight, low airborne noise, and low structure-borne noise requirements. Specifications include: Mil-M-17059A, Mil-DTL-17060, Mil-S-901, Mil-STD-167-1, Mil- STD-740, Mil-STD-2037

Suggested applications

Pumps, fans & air handling, deck equipment, underway replenishment equipment, thrusters, auxiliary propulsion, winches, capstans
