More Special Products

Motors For Circular Saws And Wood Working
Water-Cooled Special Motors
Exciters For Permanent Magnets
Exciters For Synchronous Machines
Nuclear Power Motors
Military Defence Motors
Built-In Motors
Motors For Ethylene Reactors
Drilling Motors

High voltage motor internals (stators / rotors)

High voltage motor internals, comprising stators and rotors, are essential for the efficient operation of high voltage motors.


Power Range: As Per Request
Frame Size: N/A
Number Of Poles: Any
Ingress Protection: N/A
Temperature Class: F / H
Method Of Cooling: N/A

Tacho generators

Tacho generators are precision devices used to measure the rotational speed of motors and machinery. These generators provide accurate feedback for speed control systems, ensuring consistent and reliable operation in various industrial applications. Tacho generators are commonly used in robotics, CNC machines, and automation systems where precise speed monitoring is crucial.

Die Produktdetails Entnehmen Sie Bitte Dem Dokument:
&Nbsp;
&Nbsp;Tacho Generators (Pdf)

Low voltage motor internals (stators / rotors)

Low voltage motor internals, including stators and rotors, are critical components in the construction of low voltage motors. These internals are designed to provide efficient power conversion and reliable performance in various industrial applications.


Power Range: On Request
Frame Size: On Request
Number Of Poles: On Request
Ingress Protection: On Request
Temperature Class: 155 (F)
Method Of Cooling: On Request

High slip motors (5-15% NEMA)

Type Of Protection: Safe Area
Power Range: 200 - 9.000 Kw
Frame Size: 355 - 1120
Number Of Poles: 2 - 12
Ingress Protection: Ip55
Temperature Class: B
Method Of Cooling: Ic01, Ic511, Ic611, Ic81W
Options: Im B3, Im V1

Overhung compressor motors

Type Of Protection: Safe Area
Power Range: Up To 1Mw
Frame Size: N/A - Equivalent 560
Number Of Poles: 12,16
Ingress Protection: Up To Ip55
Temperature Class: F / H
Method Of Cooling: Tefc / Open Ventilated

Industrial DC motors (Bull Electric)

Type Of Protection: Safe Area
Power Range: 0.09 To 15Kw
Frame Size: Up To 355
Number Of Poles: 4
Ingress Protection: Ip55
Temperature Class: F
Method Of Cooling: Tefc

Axial airgap motors

Type Of Protection: N/A
Power Range: 0.11 To 2.2Kw
Frame Size: N/A
Number Of Poles: 4
Ingress Protection: N/A
Temperature Class: F
Method Of Cooling: N/A

Smoke extraction motors

Type Of Protection: Safe Area - 200C, 400C, 600C
Power Range: Up To 1000 Kw
Frame Size: 80-500
Number Of Poles: 4
Ingress Protection: Up To 56
Temperature Class: 155 (F), 180 (H)
Method Of Cooling: Tefc

Motors with higher sealing

Type Of Protection: Safe Area
Power Range: Special Design - Upon Request
Frame Size: Special Design - Upon Request
Ingress Protection: Ip 67
Temperature Class: 155 (F), 180 (H)
Method Of Cooling: N/A

Mining motors - conveyor / shearer

Type Of Protection: Ex D 1M
Power Range: 200Kw To 2Mw
Frame Size: Up To 630
Number Of Poles: 4
Ingress Protection: Ip56
Temperature Class: H
Method Of Cooling: Tewjc

Semihermetic motors

Type Of Protection: Safe Area
Power Range: Special Design - Upon Request
Frame Size: Special Design - Upon Request
Ingress Protection: Ip 67
Temperature Class: F / H
Method Of Cooling: N/A
